| Cod Produs | 2020 | 2025 | 2030 | 2040 | 2040S | 2050 | 2060 |
|---|---|---|---|---|---|---|---|
| D (inch) | 2 | 2½ | 3 | 4 | 4 | 5 | 6 |
| D1(inch) | 11 | 11 | 11 | 11 | 13 | 15 | 18 |
| T (inch) | ¾ | 1 | 1 | 1 | 2 | 2 | 2 |
| T1 (inch) | ½ | ½ | ½ | ½ | ¾ | 1 | 1 |
| K (mm) | 110 | 102 | 95 | 82,5 | 102,5 | 120 | 142,5 |
| A (mm) | 250 | 300 | 300 | 300 | 350 | 400 | 450 |
| H (mm) | 1275 | 1335 | 1330 | 1320 | 1365 | 1520 | 1750 |
| H1 (mm) | 1450 | 1530 | 1530 | 1530 | 1570 | 1745 | 2035 |
| Debit (m³/h) | 20 | 30 | 40 | 60 | 80 | 120-140 | 160-200 |
| Presiune maximă (bar) | 8 | 8 | 8 | 8 | 8 | 8 | 8 |
| Greutate (kg) | 27 | 33 | 35 | 38 | 42 | 65 | 92 |
